Technical Data Sheet is a document summarizing the technical characteristics of the product. The most common characteristics for hydraulic oil fluid are Kinematic Viscosity, Viscosity Index, Density, Flash Point and Pour Point.
Move your mouse cursor to the BOLD wording, we explain the reading for you !
Below is the Shell Tellus Hydraulic fluid Data Sheet :
Move your mouse cursor to the BOLD wording, we explain the reading for you !
Below is the Shell Tellus Hydraulic fluid Data Sheet :
Shell Tellus S2 M | ISO 22 | ISO 32 | ISO 46 | ISO 68 | ISO 100 |
Fluid Type | HM | HM | HM | HM | HM |
Kinematic Viscosity (meaning) | |||||
@ 0℃, cSt | 180 | 338 | 580 | 1040 | 1790 |
@ 40℃, cSt | 22 | 32 | 46 | 68 | 100 |
@ 100℃, cSt | 4.3 | 5.4 | 6.7 | 8.6 | 11.1 |
Viscosity Index | 100 | 99 | 98 | 97 | 96 |
Density @ 15 ℃, kg/l | 0.866 | 0.875 | 0.879 | 0.886 | 0.891 |
Flash Point, ℃ | 210 | 218 | 230 | 235 | 250 |
Pour Point, ℃ | -30 | -30 | -30 | -24 | -24 |
